Detailinformationen |
|||
| Way To Install: | Inserting | Appearance: | Water |
|---|---|---|---|
| Temperature Range: | -55℃ To +125℃ | Dielectric Strength: | 1.5kVAC |
| Head Material: | Epoxy Resin | Resistance Value: | 0.3kΩ To 2000kΩ |
| Work Current: | Less Than 35mA | Customization: | Available |
| Hervorheben: | NTC temperature sensor with withstand voltage test,thermistor sensor accurate measurement device,temperature sensor work current less 35mA |
||
Produkt-Beschreibung
Product Description:
The NTC Temperature Sensor is a highly reliable and precise thermal sensing device designed to measure temperature variations accurately across a wide range. This sensor operates based on the principle of a Thermal Resistor Transducer, which means it changes its resistance value in response to temperature fluctuations. Specifically, it functions as a Temperature Dependent Resistor, making it an essential component in various applications where temperature monitoring and control are critical.
One of the most notable features of this NTC Temperature Sensor is its robust construction, starting with the head material made of high-quality epoxy resin. Epoxy resin ensures excellent durability, providing resistance against environmental factors such as moisture, chemicals, and mechanical stresses. This makes the sensor highly reliable and long-lasting, even in demanding industrial or outdoor conditions.
In terms of appearance, the sensor is designed with a water-clear finish, offering a sleek and unobtrusive look. This transparent appearance not only contributes aesthetically but also allows for easy visual inspection of the sensor’s internal components, ensuring quality and integrity during installation and maintenance.
The sensor operates efficiently within a broad temperature range from -55℃ to +125℃. This extensive range enables it to be suitable for a diverse array of applications, from cold environments such as refrigeration systems to high-temperature industrial processes. The ability to function accurately across such a wide spectrum makes it a versatile solution for temperature measurement needs.
Another critical attribute of this NTC Temperature Sensor is its thermal conductivity, rated at 0.5mW/°C. This low thermal conductivity value is essential for minimizing heat loss during temperature measurements, thereby enhancing the accuracy and responsiveness of the sensor. The precise thermal conduction characteristics ensure that the sensor can quickly detect temperature changes, providing reliable data for real-time monitoring and control systems.
The sensor is equipped with a lead length of 25mm, which strikes a balance between flexibility and compactness. This lead length allows for easy integration into various circuits and devices without excessive wiring, facilitating straightforward installation and reducing the risk of connection issues. The leads are designed to maintain stable electrical connections, further ensuring the sensor’s consistent performance over time.
Functioning as a Thermal Resistance Probe, this NTC Temperature Sensor is widely used in electronics, automotive, HVAC, and medical devices. Its ability to precisely convert temperature variations into measurable resistance changes makes it indispensable for temperature compensation, thermal protection, and environmental monitoring tasks. Whether it is embedded in a circuit board or used as part of a larger thermal management system, this sensor delivers dependable performance.
In summary, the NTC Temperature Sensor offers a combination of durable epoxy resin head material, aesthetically pleasing water-clear appearance, a wide operational temperature range of -55℃ to +125℃, low thermal conductivity of 0.5mW/°C, and a practical lead length of 25mm. These features, coupled with its function as a Thermal Resistor Transducer, Temperature Dependent Resistor, and Thermal Resistance Probe, make it an excellent choice for any application requiring precise and reliable temperature sensing. Its robust design and accurate temperature responsiveness ensure optimal performance, making it a valuable component in advanced temperature measurement systems.
Features:
- Product Name: NTC Temperature Sensor
- Type: Negative Thermal Coefficient Sensor (NTC)
- Also known as Thermistor Temperature Sensor
- Withstand Voltage Test: AC3000V 5mA for 60 seconds or AC4000V 5mA for 10 seconds
- Work Current: Less than 35mA
- Current Type: Supports both AC and DC
- Thermal Conductivity: 0.5mW/°C
- IP Code: IP64, providing protection against dust and water splashes
- Reliable Negative Thermal Coefficient Sensor for accurate temperature measurement
Technical Parameters:
| Transport Package | Carton Packing |
| Dielectric Strength | 1.5kVAC |
| Current | AC / DC |
| Appearance | Water |
| Lead Length | 25mm |
| Temperature Range | -55℃ To +125℃ |
| Thermal Conductivity | 0.5mW/°C |
| IP Code | IP64 |
| Head Material | Epoxy Resin |
| Customization | Available |
Applications:
The shinein Thermo Sensitive Thermistor, originating from China, is a highly reliable NTC Temperature Sensor designed to operate efficiently within a wide temperature range of -55℃ to +125℃. This product is an ideal choice for various application occasions and scenarios requiring precise temperature measurement and control. Its Negative Temperature Coefficient (NTC) characteristic ensures that its resistance decreases as temperature rises, making it an excellent NTC Thermocouple Detector for accurate thermal monitoring.
One of the primary application occasions for the shinein Thermo Sensitive Thermistor is in industrial temperature control systems. It can be used as a Thermal Resistance Probe to monitor temperatures in machinery, HVAC systems, and manufacturing processes where maintaining specific temperature ranges is critical. The sensor’s thermal conductivity of 0.5mW/°C allows for quick and sensitive detection of temperature changes, enabling real-time adjustments to ensure optimal operation and safety.
In the automotive industry, this NTC Temperature Sensor is used for engine temperature monitoring, battery management systems, and climate control mechanisms. Its robust design and lead length of 25mm facilitate easy installation by inserting the sensor into designated slots or housings, ensuring stable and accurate readings even in harsh environments. The work current of less than 35mA makes it energy-efficient and suitable for integration into battery-powered devices.
Furthermore, the shinein Thermo Sensitive Thermistor is widely employed in consumer electronics, including refrigerators, air conditioners, and smart home devices, where precise temperature feedback is essential for energy-saving and operational efficiency. Its compact design and reliable Negative Temperature Coefficient properties make it an indispensable component for temperature sensing and regulation.
Medical devices also benefit from this sensor’s accuracy, particularly in applications such as patient monitoring systems and laboratory instruments where temperature control is vital. The insertion installation method ensures the sensor can be positioned accurately within equipment to provide consistent temperature readings.
Overall, the shinein Thermo Sensitive Thermistor serves as a versatile and dependable NTC Thermocouple Detector and Thermal Resistance Probe across multiple industries. Its high sensitivity, broad temperature range, and easy installation make it suitable for any scenario demanding precise thermal measurement and control.
Customization:
Shinein offers customized product solutions for the Thermo Sensitive Thermistor, a high-quality Thermal Resistor Transducer designed to meet diverse temperature sensing needs. Originating from China, this NTC Thermocouple Detector belongs to our reliable Temperature Sensor series.
The sensor features a durable Epoxy Resin head material, ensuring excellent protection and long-lasting performance. With a thermal conductivity of 0.5mW/°C, it provides precise and stable temperature measurements for various applications.
Our customization services include tailoring the work current to be less than 35mA, optimizing the sensor’s efficiency and safety. Additionally, we ensure secure transport packaging with carton packing to guarantee product integrity during shipment.
Whether you require a Thermal Resistor Transducer for industrial or commercial use, Shinein’s Thermo Sensitive Thermistor can be customized to fit your specific requirements, delivering reliable and accurate temperature detection every time.
Support and Services:
Our NTC Temperature Sensor is designed to provide accurate and reliable temperature measurements in a variety of applications. For technical support, please refer to the product datasheet which includes detailed specifications, wiring diagrams, and installation guidelines to ensure optimal performance.
If you encounter any issues with the NTC Temperature Sensor, verify the wiring connections and ensure the sensor is installed in an environment within its specified temperature range. Calibration may be required periodically to maintain measurement accuracy.
We offer comprehensive services including sensor calibration, customization for specific temperature ranges, and integration support for your applications. Our technical team is dedicated to assisting you with product selection, troubleshooting, and optimizing sensor performance.
For detailed application notes, FAQs, and troubleshooting guides, please visit our online support portal. We recommend regular maintenance and inspection of the sensor to prolong its operational life and maintain measurement accuracy.
Packing and Shipping:
Product Packaging: The NTC Temperature Sensor is carefully packaged to ensure protection against damage during transit. Each sensor is placed in an anti-static bag to prevent electrostatic discharge, then secured within a custom molded foam insert inside a sturdy cardboard box. The packaging includes clear labeling with product specifications, handling instructions, and a barcode for inventory management.
Shipping: The NTC Temperature Sensor is shipped using reliable carriers with tracking options available. We ensure that all packages are handled with care and dispatched promptly to meet delivery schedules. Shipping options include standard, expedited, and express services to accommodate customer needs. International shipments comply with all relevant regulations and include appropriate documentation to facilitate smooth customs clearance.
FAQ:
Q1: What is the brand and model number of this NTC temperature sensor?
A1: The brand name is shinein and the model number is Thermo Sensitive Thermistor.
Q2: Where is the shinein Thermo Sensitive Thermistor manufactured?
A2: This NTC temperature sensor is made in China.
Q3: What type of temperature sensor is the Thermo Sensitive Thermistor?
A3: It is an NTC (Negative Temperature Coefficient) thermistor, which means its resistance decreases as temperature increases.
Q4: What applications is the shinein NTC Thermo Sensitive Thermistor suitable for?
A4: It is commonly used for temperature measurement, temperature compensation, and temperature control in various electronic devices and systems.
Q5: How do I connect the shinein Thermo Sensitive Thermistor in my circuit?
A5: The thermistor can be connected in series or parallel with other circuit components depending on the application. Typically, it is connected to a voltage divider or measurement circuit for accurate temperature sensing.
